Accessories ›
Accessories for wall terminals ›
ECONEXT® PMK for ECONEXT® condensing wall terminals ›
ECONEXT® PMK Start kit 2.0 ›
ECONEXT® PMK Start kit 2.0 Ø 60
ECONEXT® PMK Start kit 2.0 Ø 60
Are you looking for brochures, manuals or videos of this product?
| Article number: | AKPFAA500 |
|---|---|
| Packaging dimensions: | 1016 x 136 x 142 mm |
| Quantity per pack: | 1 stuks |
| Number of units: | 1 stuks |
| Minimum order quantity: | 1 stuks |
| GTIN: | 08711939266659 |
| Gross weight: | 1,29 kg |
| Net weight: | 0,998 kg |
| Inner diameter, connection 1: | 56.8 mm |
|---|---|
| Inner diameter, connection 2: | 60 mm |
| Length: | 1000 mm |
| Outer diameter: | 60 mm |
| Outer diameter connection 1: | 60 mm |
| Wall thickness: | 1.6 mm |
| Working length: | 942 mm |
| Colour: | Black |
| Dry (non-condensing): | No |
| Material: | Plastic |
| Material quality: | Polypropylene (PP) |
| Material sealing: | Ethylene-propylene diene monomer rubber (EPDM) |
| Max. medium temperature (continuous): | 120 °C |
| Negative (negative pressure): | No |
| Number of lips: | 2 |
| Only suitable for air supply: | No |
| Position of lips: | Straight |
| Positive (overpressure): | Yes |
| Production method: | Seamless |
| RAL-number: | 9005 |
| Surface protection: | Other |
| Wet (condensing): | Yes |
| With clamping strip: | No |
| With lip ring: | Yes |
| With pull-out protection: | No |
ECONEXT® PMK Start kit 2.0 Ø 60
Available in 1 alternatives
| Art.nr. | Ø mm | RAL | Length (mm) | b | 3 | c |
|---|---|---|---|---|---|---|
| AKPFAA500 | 60 | 9005 | 1000 | 1 | 66 | 869 |
Suitable for
ECONEXT® PMK pipe L1000 Ø 60
ECONEXT® PMK pipe L500 Ø 60
ECONEXT® PMK bend 45º Ø 60
ECONEXT® wall terminal 2.0 condensing Ø 60/100 with PP flue gas pipe
